Phoenix Contact 3201369 Ferrule 0.5 mm² Insulated White 1000 pieces

Phoenix Contact manufactures the 3201369 ferrule, featuring a partially insulated design in white, suitable for 0.5 mm² wire applications. This product, sold in packages of 1000 pieces, ensures secure connections and reliable electrical conductivity. Commonly used in industrial settings, it is ideal for crimping and terminating electrical wires.

Insulation	Partially insulated
Colour	White
Pin Length	14mm
Maximum Wire Size mm2	0.5mm²
Number of Entries	1
AWG size	20
Construction type	Standard
Contact Material	Cathode copper, tin plated
Country colour code	DIN
Cross-section range	0.5 mm² x 8 mm
For cables resistant to short circuit	false
Halogen free	true
Industrial packaging	Yes
Insulated	true
Material	Copper
Material insulation	Other
Maximum Wire Size AWG	22
Misc Attribute	AI 0,5 - 8 WH-B
Nominal cross section	0.5mm²
Reel/roll packaging	false
Sleeve length	8mm
Surface protection	Other
Temperature Range	+105°C
Total Length	N/Amm
Type	Ferrule
With identification flag	false
