Phoenix Contact 3201026 Twin Ferrule 10mm² Partially Insulated Ivory 100 pieces

Phoenix Contact's 3201026 is a partially insulated twin ferrule designed for secure electrical connections in 10 mm² wires. Its ivory insulation enhances safety, while its dual wire capability is ideal for efficient crimping in control panel assemblies. Typical applications include terminal blocks and wiring systems where reliable connections are critical.

Insulation	Partially insulated
Colour	Ivory
Pin Length	22mm
Maximum Wire Size mm2	10mm²
Number of Entries	2
AWG size	8
Construction type	Twin cable end sleeve
Contact Material	Cathode copper, tin plated
Cross-section range	10 mm² x 14 mm
For cables resistant to short circuit	false
Halogen free	true
Insulated	true
Material	Copper
Material insulation	Other
Maximum Wire Size AWG	2
Misc Attribute	AI-TWIN 2X10 -14 RD
Nominal cross section	10mm²
Reel/roll packaging	false
Sleeve length	14mm
Surface protection	Other
Temperature Range	+105°C
Total Length	N/Amm
Type	Twin ferrule
With identification flag	false
