Phoenix Contact 1913934 COMBICON 3-pin green spring-loaded Terminal

The Phoenix Contact 1913934 is a green, spring-loaded terminal block featuring three pins. This component is typically used for secure and reliable electrical connections on printed circuit boards. Ideal for applications in electronics, it provides ease of use through its spring power terminal design.

Pitch	3.5mm
No of Ways Per Row	3
Current Rating	4A
Colour	Green
Wire Gauge (AWG)	20
Wire Gauge (mm²)	0.5mm²
Actuation direction	Parallel (to the PCB)
Angle contact/conductor connection	Other
AWG (min.)	26
Coating housing	N/A
Connectable cable type	Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve	- - -mm²
Connectable conductor cross section fine-strand without cable end sleeve	- - -mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.12 - 0.5mm²
Connector cross section	0.12 - 0.5mm²
Connector orientation	Parallel (to the PCB)
Contact Material	Cathode copper, tin plated
Contact Type	Bus
Cross section (inflexible) (min.)	0.12mm²
Degree of protection (IP), mounted	N/A
Enclosure material	Polyamide
Height	9.50mm
Housing Colour	Green
Housing Material	Other
Inflammability class of insulation material according to UL94	V0
Length	8.50mm
Material contact	Copper
Material insulation body	Other
Material of contact surface	Tin
Min. stripping length	6mm
Misc Attribute 1	FK-MPT 0,5/ 3-ST-3,5
Misc Attribute 2	FK-MPT 0,5/3 ST-3,5
Modular spacing connections	3.5mm
Modular spacing contacts	3.5mm
Nominal Voltage	250V
Number of pins	3
Number of plug-in contact rows	1
Number of Poles	3
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	4A
Rated Surge Voltage	2.5kV
Rated voltage	250V
Series	FK-MPT
Stripping length (max.)	6mm
Type	Spring-loaded terminal
Type of connection	Other
Type of electric connection	Spring clamp connection
Width	11.00mm
Wire protection	Yes
With protective conductor	N/A
