Phoenix Contact 1844223 MINI COMBICON Pin Housing PCB 3 Pins 3.5 mm Spacing

The phoenix contact pin housing PCB MC is a component featuring three pins with a contact spacing of 3.50 mm, suitable for a nominal current of 8 A. Manufactured by Phoenix Contact, this connector is ideal for secure electrical connections on circuit boards. It is commonly used in electronic assemblies and devices requiring reliable component mounting and connectivity.

Body Style	Plug, horizontal mount
Pitch	3.5mm
No of Ways Per Row	3
No. of Rows	1
Current Rating	8A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
A	7.00mm
Angle PCB/contact	N/A
Connection	Print
Connector model	Other
Connector orientation	Parallel (to the PCB)
Connector System	wire-to-board
Contact Material	Tin plated
Contact Type	Pin
Diameter connection pin	1.2mm
Dim	(L x W x H) 9.20 x 11.90 x 10.65 mm
Height	10.65mm
Housing Colour	Green
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	9.20mm
Length pin	3.4mm
Material insulation body	Other
Material of contact surface	Other
Misc Attribute	MC 1,5/ 3-G-3,5
Modular spacing connections	3.5mm
Modular spacing contacts	3.5mm
Nominal Voltage	160V
Number of plug-in contact rows	1
Number of Poles	3
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	2.5kV
Rated voltage	160V
Series	MC
Suitable for PCB thickness	N/Amm
Total number of pins	3
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
Width	11.90mm
