Phoenix Contact 1836202 4-Way Right Angled Header, 5.08mm Pitch, 8A Green

MPN: 1836202
Brand: Phoenix Contact
EAN-13: 2050000257575
Order Code: 51-4797

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
10+	£0.954

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 1

Despatched within 4 working days - 37 in stock

Product Details

Right-angled green PCB header from Phoenix Contact, 5.08 pitch, with 4 ways.

Low construction height of MC 1.5 plug-family
Plug-in direction parallel to conductor axis
Length 9.2mm
Hole diameter 1.2mm
Nominal current 8A
Colour: green
Manufacturer's part 1836202

Body Style	Horizontal Closed End Header
Pitch	5.08mm
No of Ways Per Row	4
No. of Rows	1
Current Rating	8A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Angle PCB/contact	N/A
Connector model	Other
Contact Type	Pin
Diameter connection pin	1.2mm
Housing Colour	Green
Inflammability class of insulation material according to UL94	V0
Length pin	3.4mm
Material insulation body	Other
Material of contact surface	Other
Modular spacing connections	5.08mm
Modular spacing contacts	5.08mm
Number of plug-in contact rows	1
Number of Poles	4
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	8A
Rated Surge Voltage	4kV
Rated voltage	320V
Suitable for PCB thickness	N/Amm
Type	Pin housing PCB
Type of banding	Carton (for SMD)
Type of connection	N/A
Type of electric connection	Other
Type of fastening	Other
Type of PCB fastening	N/A
