Phoenix Contact 1803578 MINI COMBICON socket housing 2 pins 3.81mm spacing

Image Representative of Range

Phoenix Contact 1803578 MINI COMBICON socket housing 2 pins 3.81mm spacing

Phoenix Contact
Order Code:

06-1983

Brand: Phoenix Contact MPN: 1803578 EAN-13: 2050000437588
Qty Unit Price (Ex VAT)
2+ £2.08
75+ £1.89
250+ £1.72
500+ £1.59
1000+ £1.47
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
610 in stock, despatched in 4 working days

Phoenix Contact provides a socket housing cable with 2 pins and a contact spacing of 3.81 mm. It features a screw-type connector, supporting a nominal current of 8 A. This component is typically used in electrical and electronic connections where secure, reliable connectivity is essential.
No. of Rows 1
Current Rating 8A
Wire Gauge (AWG) 16
Wire Gauge (mm²) 1.15mm²
Colour Green
A 3.81mm
AWG (min.) 28
Case Material PA
Connector cross section 1.15mm²
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Tin plated
CS 3.81mm
Dim (L x W x H) 8.41 x 16.10 x 11.10 mm
Height 11.10mm
Industrial packaging Yes
Length 8.41mm
max. cross section 1.5mm²
Min. cross section 0.14mm²
Misc Attribute MC 1,5/ 2-ST-3,81
Nominal Voltage 160V
Pins per row 2
Series MC
Stripping length (max.) 7.00mm
Total number of pins 2
Type Socket housing cable
Width 16.10mm
