Phoenix Contact 1711268 Phoenix Contact socket housing 2-pin 76A 1000V

Phoenix Contact manufactures the socket housing cable SPC with a total of 2 pins and a contact spacing of 10.16 mm. This component is often used in industrial applications due to its reliable connection features. The product is available in packaging units containing 50 pieces each.

Body Style	Socket, straight
Pitch	10.16mm
No of Ways Per Row	2
No. of Rows	1
Current Rating	76A
Colour	Green
Wire Gauge (AWG)	4
Wire Gauge (mm²)	25mm²
Angle contact/conductor connection	Other
AWG (min.)	18
Coating housing	N/A
Connectable cable type	Tubular cable
Connectable conductor cross section fine-strand with cable end sleeve	0.75 - 10mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.75 - 16mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.75 - 16mm²
Connector contact surface	Tin plated
Connector System	wire-to-board
Contact Material	Silver plated
Contact Type	Bus
Degree of protection (IP), mounted	N/A
Dim	(L x W x H) 20.32 x 44.50 x 25.10 mm
Height	25.10mm
Housing Colour	Green
Housing Material	Other
Industrial packaging	Yes
Inflammability class of insulation material according to UL94	V0
Length	20.32mm
Material contact	Copper
Material insulation body	Polyamide (PA)
Material of contact surface	Silver
max. cross section	16mm²
Min. cross section	0.75mm²
Misc Attribute	SPC 16/ 2-ST-10,16
Modular spacing connections	10.16mm
Modular spacing contacts	10.16mm
Nominal Voltage	1000V
Number of plug-in contact rows	1
Number of Poles	2
Operating Temperature	-40 - 100°C
Overvoltage category	III
Pollution degree	2
Rated current In	76A
Rated Surge Voltage	6kV
Rated voltage	1000V
Series	SPC
Stripping length (max.)	18.00mm
Total number of pins	2
Type	Socket housing cable
Type of connection	Other
Type of electric connection	Spring clamp connection
Width	44.50mm
With protective conductor	N/A
