Phoenix Contact 1704857 PTSM socket housing 4 pins 2.50 mm contact spacing

Image Representative of Range

Phoenix Contact 1704857 PTSM socket housing 4 pins 2.50 mm contact spacing

Phoenix Contact
Order Code:

06-1834

Brand: Phoenix Contact MPN: 1704857 EAN-13: 2050001729088
Qty Unit Price (Ex VAT)
3+ £1.54
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
114 in stock, despatched in 4 working days

Phoenix Contact manufactures the socket housing cable PTSM with a total of 4 pins and a contact spacing of 2.50 mm. This compact terminal block is ideal for applications requiring reliable electrical connections in tight spaces. Common uses include use in electronic devices and control systems where space and precision are critical.
Body Style Socket, straight
Pitch 2.5mm
No of Ways Per Row 4
No. of Rows 1
Current Rating 6A
Colour White
Wire Gauge (AWG) 20AWG
Wire Gauge (mm²) 0.5 mm²
AWG (min.) 24
Connector System wire-to-board
Contact Material Tin plated
Dim (L x W x H) 5.00 x 15.00 x 11.10 mm
Height 11.10mm
Industrial packaging No
Length 5.00mm
max. cross section 0.5mm²
Min. cross section 0.2mm²
Misc Attribute 1 PTSM 0,5/ 4-P-2,5 WH
Misc Attribute 2 Connector part
Nominal Voltage 160V
Series PTSM
Stripping length (max.) 6.00mm
Total number of pins 4
Width 15.00mm
