Phoenix Contact 1407730 HC-B 10 Pin Inset + PE Plug & Clip 1 piece

The Phoenix Contact 1407730 Pin Inset HC-B 10 + PE Plug & Clip is a high voltage, heavy duty connector designed for industrial applications. It features robust multi core connectivity, making it ideal for electrical engineering use. Typically employed in industry-grade environments, this connector ensures reliable performance under demanding conditions.

Type	Pin inset
Ambient temperature	125 - 125°C
Colour	Grey
Connectable conductor cross section fine-strand with cable end sleeve	- - -mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.14 - 2.5mm²
Connectable conductor cross section multi-wired	0.14 - 2.5mm²
Connectable conductor cross section solid-core	- - -mm²
Connection	Plug & Clip
Contact insert without contacts	false
Contact Type	Pin
Depth	64mm
Diameter plug-in contact	2.5mm
Height	34.4mm
Inflammability class of insulation material according to UL94	V0
Leading Contact (Pe)	Yes
Material connector insert	Thermoplastic
Material contact	Other copper alloys
Material of contact insert	Thermoplastic
Material of contact surface	Other
Min. number of insertion cycles	500
Number of control contacts	0
Number of Poles	10
Number of power contacts	10
Number of Ways	10 + PE
Operating Temperature	-40 - 125°C
Overvoltage category	III
Packaging Type	Piece
Pollution degree	3
Rated current In	16A
Rated Surge Voltage	6kV
Rated voltage	500V
Series	HC-B
Type of electric connection	Spring clamp connection
Width	34mm
Wire Gauge (mm²)	0.14mm²
With protective conductor	true
With wire protection	false
