Panasonic MEP1G92Z Limit Switch 24V 5A Spring-Loaded Rod IP67 Nylon Tip

Panasonic's MEP1G92Z is a limit switch designed for industrial applications, featuring a spring-loaded rod and rated at 24 V and 5 A. With IP67 protection, it is highly reliable in harsh environments, offering robust durability. Typical applications include use as a position switch or emergency power-off button in automation systems.

Type	Limit switch
Cable Length	1.00m
Connection	Open end cable
Dim	(L x W x H) 49 x 31.5 x 30 mm
Durability	10,000,000
Factory colour	Black
Height	30mm
IP Rating	IP67
Length	49mm
Material	Plastic
Max. temperature	+70°C
Min. temperature	-20°C
Operation type	Spring-loaded rod
Switching current (max.)	5A
Switching Voltage	24V
Width	31.5mm
