Panasonic FX102PCC2 FX100 Light-wave Amplifier Energy Saving Teach-In

Panasonic's Light-wave Conductor Amplifier FX102PCC2 uses a glass fibreglass fibre cable. It features enhanced signal amplification which makes it ideal for use in light barriers. The amplifier is typically used in precision optical applications.

Type	FO amplifier
IP Rating	IP40
Ambient temperature	-10 - +55°C
Cable Length	2.00m
Connector	Cable, open end
Dim	(L x W x H) 65.5 x 9 x 30 mm
Height	30mm
Length	65.5mm
Max. operating voltage	24V DC
Maximum Temperature	+55°C
Min. operating voltage	12V DC
Min. temperature	-10°C
Misc Attribute 1	Light wave conductor amplifiers
Output	PNP-Transistor 100mA
Output Type	PNP
Pick-up time (details)	250µs
Response Time	2.5ms
Width	9mm
