OBO Bettermann 1790 61 225 FL Connector Clip 2 Pins 0.2-2.5mm² Trans-Orng

Image Representative of Range

OBO Bettermann 1790 61 225 FL Connector Clip 2 Pins 0.2-2.5mm² Trans-Orng

OBO Bettermann
Standard range
Order Code:

05-5885

Brand: OBO Bettermann MPN: 1790
Qty Unit Price (Ex VAT)
1+ £0.551
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
111 in stock, despatched in 4 working days

OBO Bettermann's 1790 61 225 FL connector clip is a transparent-orange terminal designed for use with flexible and fixed wires ranging from 0.2 to 2.5 mm². With two pins, this eu standard terminal ensures secure electrical connections. It is ideal for lighting installations and general electrical wiring applications.
Connection Pull spring
Connector clip features Actuator
Cross section (flexible) (max.) 2.5mm²
Cross section (flexible) (min.) 0.2mm²
Cross section (inflexible) (max.) 2.5mm²
Cross section (inflexible) (min.) 0.2mm²
Dim (L x W) 21 mm x 11.9 mm
Factory colour Transparent-orange
Industrial packaging No
Length 21mm
Manufacturer part # 1790
Nominal current 24A
Nominal current - rounded value 24A
Nominal voltage 450V AC
Number of pins 2
Stripping length 9mm
Type Connector clip
Width 11.9mm
