Neutrik NBNC75BLP7 Rear Twist BNC Plug Straight 75Ω for HDTV Belden 7731A

Name: Neutrik NBNC75BLP7 Rear Twist BNC Plug Straight 75Ω for HDTV Belden 7731A
Brand: Neutrik
Price: 3.29 GBP
Availability: InStock

Standard range

Order Code:

12-5166

Brand: Neutrik MPN: NBNC75BLP7 EAN-13: 7613187004872

RoHS Compliant
Country of Origin: Liechtenstien
Free UK shipping available
View Full Product Range (12)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£3.29

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

12 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Neutrik NBNC75BLP7 is a straight BNC connector plug designed for 75-ohm applications, known for its reliable performance in high-frequency connections. Manufactured by Neutrik, it features the Rear Twist system, making it ideal for use in broadcast and professional audio-visual projects. It is commonly used in coaxial cable systems for transferring signals in television, radio, and other telecommunications applications.

Cable diameter (details)	4-8mm
Cable Ø	6.30mm
Cable type	RG 59-/ video cable
Connection	Crimp
Connector type	Plug, straight
Contact material	Gold plated
Frequency	0 - 3GHz
Height	1.00mm
Impedance	75Ω
Manufacturer part #	NBNC75BLP7
Material (details)	Brass, nickel-plated with full PA6 insulation
Misc Attribute 1	NBNC 75 BLP 7
Misc Attribute 2	NBNC75BLP7
Misc Attribute 3	RearTwist®
Seal	Push-Pull
Seal type	Push-Pull
Temperature range	-30 - +40°C
Type	BNC connector
Voltage	500 V/AC, rms.
Weight	15.0000
Width	9.00mm
