Murrelektronik 6686309 Control Transformer 230V 400V 630VA Key Hole

Murr Elektronik
Order Code:

05-4955

Brand: Murr Elektronik MPN: 6686309 EAN-13: 4048879066211
Qty Unit Price (Ex VAT)
1+ £100.46
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Murrelektronik control transformer, model 6686309, is an isolation transformer with a capacity of 630 VA. It is designed for 400 V to 230 V single-phase AC applications. Typical uses include automation and control systems where safe voltage transformation is essential.
Type Control transformer
Connection Spring-loaded terminal
Dim (L x W x H) 144.6 x 150 x 112.5 mm
Frequency 50 - 60Hz
Height 112.5mm
Input Voltage 230/400V AC
Input voltage (number x voltage) 1 x 230 V, 400 V
Insulation class T 40/B
Length 144.6mm
Max. ambient temperature +40°C
Min. ambient temperature -20°C
Misc Attribute MST 0630-230-400/230
Number of Inputs 1
Number of Outputs 1
Output Voltage 230V AC
Output voltage (number x voltage) 1 x 230 V AC
Power 630VA
Primary Voltage 230/400V AC
Protection Class IP20
Standards Complies with EN 61558 · Contact protection as per EN 60529
Width 150mm
