Molex's 936040033 Universal enclosure is an aluminium die-cast box that is powder-coated in black (RAL 9005). It is designed for industrial applications, offering durability and protection for electronic components. Typically used to house sensitive equipment in harsh environments.
| Type |
Universal enclosure |
| Enclosure Length |
252mm |
| Enclosure Width |
215mm |
| Enclosure Height |
91mm |
| Colour |
Black (RAL 9005) |
| Protection Rating |
None |
| Base unit of measure |
PC |
| Base unit of measure desc |
piece |
| China ro h s status |
Compliant per SJ/T 11365-2006 |
| Delivery unit |
8 |
| Design registration eligibility |
true |
| Dim |
(L x W x H) 252 x 215 x 91 mm |
| ELV status |
Not Relevant |
| Enclosure coating |
Polyester Powder |
| Enclosure color |
Black RAL 9005 |
| Engineering number |
8000.6265.1 |
| Engineering Part No |
8000.6265.1 |
| Engineering Series Name |
Alum Enclos & acc. |
| Engineering Series No |
93604 |
| First published date |
2015-04-15 |
| G a d s l/ i m d s |
Not Relevant |
| H f l h status |
Low-Halogen per IEC 61249-2-21 |
| Inside height |
202mm |
| Inside Width |
239mm |
| Internal depth |
85mm |
| Internal dimensions |
239 x 202 x 85mm |
| IP Rating |
IP66, IP69 |
| Material |
powder-coated |
| Material enclosure |
Die-cast Aluminum |
| Material type |
Finished Goods |
| Minimum line quantity |
104 |
| Misc Attribute |
MWE Industrial Solution |
| Mounting Style |
External Flanges |
| Net weight |
1361.500/g |
| Outside dimensions |
252 x 215 x 91mm |
| Packaging Type |
Carton |
| Product category |
Die-cast Enclosures |
| Product name |
Heavy-Duty Connectors |
| Product number display |
936040033 |
| Product number hyphen |
93604-0033 |
| Product number sap |
0936040033 |
| Reach status |
Not Contained per D(2025)7771-DC (04 Feb 2026) |
| Reference series |
93604 |
| Ro h s status |
Compliant per EU 2015/863 |
| Sampleable |
False |
| Standard |
ANSI/UL 50, ANSI/UL 50 E, CSA C22.2 No.94-1-2, EN 60670-1, EN 62208, EN-60670-22, NMX-J235/1-2 |
| Taxonomy |
Die-cast Enclosures |
| Temperature range operating |
-40° to +125°C |
| Upc |
887191869087 |
