Molex 532530370 Micro-latch 3-pin Header 2mm Pitch Vertical Tray

Molex
Order Code:

05-4068

Brand: Molex MPN: 532530370 EAN-13: 2050007122166
Qty Unit Price (Ex VAT)
25+ £0.215
125+ £0.132
500+ £0.123
2500+ £0.115
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
4,707 in stock, despatched in 4 working days

The Molex built-in pin strip features three pins with a contact spacing of 2 mm. It is commonly used in electronic devices for reliable electrical connections. Ideal for use in compact circuit boards, it is supplied in a tray for ease of handling and storage.
Type Built-in pin strip (standard)
Number of Positions 3
Number of Rows 1
Application Signal, Wire-to-Board
Base unit of measure PC
Base unit of measure desc piece
Board contact surface Tin
Breakaway No
Case Material Nylon (NL)
China ro h s status Compliant per SJ/T 11365-2006
Circuits loaded 3
Circuits maximum 3
Coating thickness (PCB side) 1.016µm
Colour resin Natural
Component type PCB Header
Connection Soldering
Connector coating thickness 1.016µm
Connector contact surface Tin
Connector orientation Perpendicular (to the PCB)
Connector System wire-to-board
Contact Material Brass
Cross Section 2mm
Current maximum per contact 2.0A
Delivery unit 8000
Design registration eligibility true
Durability mating cycles max 30
ELV status Not Relevant
Engineering number 53253-0370
Engineering Part No 53253-0370
Engineering Series Name Hdr Str
Engineering Series No 53253
First mate last break No
First published date 2007-06-08
Flammability 94V-0
G a d s l/ i m d s Compliant with Exemption 33; 44
Glow wire capable No
H f l h status Not Low-Halogen per IEC 61249-2-21
Lock to mating part Yes
Material metal Brass
Material plating mating Tin
Material plating termination Tin
Material resin Nylon
Material type Finished Goods
Max. temperature +105°C
Min. temperature -40°C
Minimum line quantity 24000
Misc Attribute Molex MOL Power & Signal Sol.
Net weight 133.000/mg
Nominal Current 2A
Nominal Voltage 125V
Orientation Vertical
Packaging Type Tray
Pc tail length 3.50mm
Pcb locator No
Pcb retention Yes
Pcb thickness recommended 1.60mm
Pitch mating interface 2.00mm
Plating min mating 1.016µm
Plating min termination 1.016µm
Polarized to mating part Yes
Polarized to pcb No
Primary pack qty 1000
Product name Micro-Latch
Product number display 532530370
Product number hyphen 53253-0370
Product number sap 0532530370
Reach status Not Contained per D(2025)7771-DC (04 Feb 2026)
Reference series 53253
Ro h s status Compliant per EU 2015/863
Sampleable True
Shrouded Partial
Stackable No
Taxonomy PCB Headers and Receptacles
Temperature range operating -55° to +105°C
Termination interface style Through Hole
Ul E29179
Upc 756054354018
Voltage maximum 125V
