Molex 528061610 Easy-on Sil Socket 16 Pins 1mm Pitch Non-zif Smt

Image Representative of Range

Molex 528061610 Easy-on Sil Socket 16 Pins 1mm Pitch Non-zif Smt

Molex
Order Code:

05-4050

Brand: Molex MPN: 528061610 EAN-13: 2050008575046
Qty Unit Price (Ex VAT)
20+ £0.330
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
224 in stock, despatched in 4 working days

The Molex SIL socket 528061610 is a standard connector with 16 pins and 1.00 mm contact spacing. This reliable component is ideal for high-density applications and ensures secure electrical connections. Typically used in electronics and communication devices, it is supplied in a tray for convenient handling.
Type SIL socket (standard)
Number of Positions 16
Actuator Type Non-ZIF
Base unit of measure PC
Base unit of measure desc piece
China ro h s status Compliant per SJ/T 11365-2006
Circuits loaded 16
Color resin Natural
Connection SMD
Connector orientation Perpendicular (to the PCB)
Cross Section 1.00mm
Current maximum per contact 0.5A
Delivery unit 6000
Design registration eligibility true
Durability mating cycles max 10
Elv status Not Relevant
Engineering number 52806-1610
Engineering Series Name 1.0 NON ZIF ST TH
Engineering Series No 52806
First published date 2007-05-03
G a d s l/ i m d s Compliant with Exemption 44
H f l h status Not Low-Halogen per IEC 61249-2-21
Mated height 5.40mm
Material metal Phosphor Bronze
Material plating mating Tin
Material plating termination Tin
Material resin High Temperature Thermoplastic
Material type Finished Goods
Minimum line quantity 18000
Net weight 448.701/mg
Orientation Vertical
Packaging Type Tray
Pc tail length 3.20mm
Pcb locator No
Pcb mounting Through Hole - Kinked Pin
Pcb retention No
Pcb thickness recommended 1.60mm
Pitch mating interface 1.00mm
Pitch termination interface 1.00mm
Plating min mating 0.914µm
Plating min termination 0.914µm
Polarized to pcb No
Primary pack qty 150
Product name Easy-On
Product number display 528061610
Product number hyphen 52806-1610
Product number sap 0528061610
Reach status Not Contained per D(2025)7771-DC (04 Feb 2026)
Reference series 52806
Ro h s status Compliant per EU 2015/863
Sampleable False
Stackable No
Taxonomy FFC / FPC Connectors
Temperature range operating -20° to +80°C
Ul E29179
Upc 800753632493
Voltage maximum 50V
Wire cable type FFC/FPC
