Molex 511910200 Mini-latch Receptacle 2-pin 2.5mm Spacing Guide Rails

The Molex socket housing cable is manufactured by Molex and features a total of 2 pins with a contact spacing of 2.5 mm. This compact housing is designed for secure cable connections, providing reliability in various electronic applications. Typical uses include consumer electronics and low-power electrical devices.

Type	Socket housing cable
Pitch	2.5mm
Number of Ways	2
Number of Rows	1
Mounting Type	Cable mount
Mounting Direction	Straight
Application	Signal, Wire-to-Board, Wire-to-Wire
Base unit of measure	PC
Base unit of measure desc	piece
Case Material	Nylon (NL)
China ro h s status	Compliant per SJ/T 11365-2006
Circuits maximum	2
Connector Type	Socket
CS	2.5mm
Delivery unit	20000
Design registration eligibility	true
ELV status	Not Relevant
Engineering number	51191-0200
Engineering Part No	51191-0200
Engineering Series Name	2.5 WTB HSG
Engineering Series No	51191
First published date	2007-05-16
G a d s l/ i m d s	Not Relevant
Gender	Receptacle
Glow wire capable	No
H f l h status	Low-Halogen per IEC 61249-2-21
Material resin	Nylon
Material type	Finished Goods
Maximum Temperature	+105°C
Min. temperature	-40°C
Minimum line quantity	40000
Misc Attribute	Molex MOL Power & Signal Sol.
Net weight	276.600/mg
Packaging Type	Bag
Panel mount	No
Primary pack qty	1000
Product name	Mini-Latch
Product number display	511910200
Product number hyphen	51191-0200
Product number sap	0511910200
Reach status	Not Contained per D(2025)7771-DC (04 Feb 2026)
Reference series	51191
Replacement part number	50375023
Ro h s status	Compliant per EU 2015/863
Sampleable	False
Stackable	No
Taxonomy	Connector Housings
Temperature range operating	-40° to +105°C
Ul	E29179
Upc	800753327702
