The Molex 190130029 blade receptacle is a crimp connector with a width of 6.35 mm and thickness of 0.81 mm, featuring a blue insulation for enhanced protection. This component is commonly used in electrical applications to securely connect wiring, ensuring efficient electrical flow. Its design is suited for use in automotive and industrial environments where reliable connections are critical.
| Insulation |
Nylon (NL) |
| Colour |
Blue |
| Tab Width |
6.35mm |
| Tab Thickness |
0.81mm |
| Gender |
Female |
| Barrel Type |
Closed - Brazed |
| Base unit of measure |
PC |
| Base unit of measure desc |
piece |
| China ro h s status |
Compliant per SJ/T 11365-2006 |
| Color resin |
Blue |
| Comments |
Loose in Bag |
| Connector thickness |
0.81mm |
| Connector Width |
6.35mm |
| Contact Material |
Brass tin plated |
| Cross-section range |
1.3 - 2mm² |
| Csa |
LR18689 |
| Delivery unit |
2000 |
| Design registration eligibility |
true |
| ELV status |
Not Relevant |
| Engineering number |
BB-2318 |
| First published date |
2007-05-15 |
| Flammability |
94V-2 |
| G a d s l/ i m d s |
Not Relevant |
| Glow wire capable |
No |
| H f l h status |
Low-Halogen per IEC 61249-2-21 |
| Insulated |
Fully |
| Insulation Type |
Insulated |
| Lock to mating part |
No |
| Material metal |
Brass |
| Material plating mating |
Tin |
| Material plating termination |
Tin |
| Material resin |
Nylon |
| Material type |
Finished Goods |
| max. cross section |
2mm² |
| Maximum Wire Size AWG |
14 |
| Min. cross section |
1.3mm² |
| Minimum line quantity |
2000 |
| Misc Attribute 2 |
Quick disconnect |
| Net weight |
1.256/g |
| Orientation |
Straight |
| Packaging Type |
Bag |
| Plating min mating |
2.540µm |
| Plating min termination |
2.540µm |
| Polarized to mating part |
Yes |
| Primary pack qty |
500 |
| Product name |
InsulKrimp |
| Product number display |
190130029 |
| Product number hyphen |
19013-0029 |
| Product number sap |
0190130029 |
| Reach status |
Not Contained per D(2025)7771-DC (04 Feb 2026) |
| Reference series |
19013 |
| Ro h s status |
Compliant per EU 2015/863 |
| Sampleable |
True |
| Size |
6.35 x 0.81 mm |
| Taxonomy |
Quick Disconnects |
| Temperature Range |
105°C |
| Temperature range operating |
105°C |
| Type |
Blade receptacle |
| Ul |
E79133 |
| Upc |
822350963244 |
| Voltage maximum |
600V AC |
| Weight |
1.256g |
| Wire insulation diameter |
4.04mm max. |
| Wire size awg |
14, 16 |
| Wire size mm |
1.30-2.00 |
