The Molex 1731130061 D-SUB plug features 26 pins and is designed for soldering, suitable for reliable connections in electronic applications. Manufactured by Molex, this connector is ideal for use in communications and data transfer systems. Its robust construction ensures durability in various industrial environments.
| Type |
D-SUB plug |
| Plug / Socket |
Socket |
| Mounting Type |
Soldering |
| No. of Ways |
26 |
| Mounting Direction |
Straight |
| Connection Angle |
180° |
| Plating Material |
Gold on nickel |
| Base unit of measure |
PC |
| Base unit of measure desc |
piece |
| China ro h s status |
Compliant per SJ/T 11365-2006 |
| Circuits loaded |
26 |
| Circuits maximum |
26 |
| Color resin |
Black |
| Contact Material |
Copper alloy |
| CS |
1.98mm |
| Current maximum per contact |
3.0A |
| Delivery unit |
200 |
| Design registration eligibility |
true |
| ELV status |
Not Relevant |
| Engineering number |
CT15-26S |
| Engineering Part No |
CT15-26S |
| Engineering Series Name |
FCT HD D-SUB |
| Engineering Series No |
173113 |
| Factory colour |
Black |
| First published date |
2019-06-07 |
| G a d s l/ i m d s |
Not Relevant |
| Gender |
Female |
| H f l h status |
Not Reviewed per IEC 61249-2-21 |
| IP Rating |
IP20 |
| Magnetic |
Yes |
| Material contact |
Copper Alloy |
| Material resin |
PBT |
| Material shell |
Steel |
| Material type |
Finished Goods |
| Mating cycles |
50 |
| Minimum line quantity |
200 |
| Misc Attribute |
Molex MOL Power & Signal Sol. |
| Net weight |
8.000/g |
| No. of Rows |
3 |
| Number of Rows |
3 |
| Packaging Type |
Tray |
| Panel mount |
Rear |
| Panel mount method |
Flange |
| Pcb locator |
No |
| Pcb retention |
No |
| Pitch mating interface |
1.98mm |
| Pitch termination interface |
1.98mm |
| Plating shell |
Nickel |
| Polarized to mating part |
Yes |
| Ports |
1 |
| Primary pack qty |
50 |
| Product name |
FCT Products |
| Product number display |
1731130061 |
| Product number hyphen |
173113-0061 |
| Product number sap |
1731130061 |
| Reach status |
Not Contained per D(2025)4165-DC (25 June 2025) |
| Reference series |
173113 |
| Ro h s status |
Compliant per EU 2015/863 |
| Sampleable |
True |
| Shielded |
Yes |
| Taxonomy |
D-Sub Connectors |
| Temperature Range |
-55° - +105 °C.°C |
| Temperature range operating |
-55° to +105°C |
| Termination Style |
Solder Cup |
| Upc |
889056324441 |
| Waterproof dustproof |
No |
| Waterproof dustproof type |
IP20 |
| Wire size awg |
22 |
