The Molex square connector, part number 1212070095, adheres to DIN 43650 standards and features two pins. It is known for its reliability and robust construction, making it ideal for use in industrial environments. Typically, this connector is utilised in applications requiring secure and efficient electrical connections, such as hydraulic systems and pneumatics.
| Type |
Square connector |
| Conductor Material |
Brass silver plated |
| Number of Positions |
2 |
| Base unit of measure |
PC |
| Base unit of measure desc |
piece |
| China ro h s status |
50 Image per SJ/T 11365-2006 |
| Coupling type |
External Thread |
| Current maximum per contact |
16.0A |
| Delivery unit |
50 |
| Design registration eligibility |
true |
| Diagnostics leds |
Yes |
| Diagnostics port |
No |
| Display |
LED |
| Elv status |
Not Relevant |
| Engineering number |
S28200TC410R |
| Engineering Part No |
S28200TC410R |
| First published date |
2013-02-14 |
| Form |
A - 18mm |
| G a d s l/ i m d s |
Not Relevant |
| H f l h status |
Low-Halogen per IEC 61249-2-21 |
| IP Rating |
IP65, IP67 |
| Material connector body |
Polyamide |
| Material contact |
Brass |
| Material plating mating |
Silver |
| Material type |
Finished Goods |
| Max. temperature |
+90°C |
| Min. temperature |
-40°C |
| Minimum line quantity |
100 |
| Misc Attribute 2 |
A standard |
| Net weight |
19.661/g |
| Orientation |
90° Angle |
| Pitch mating interface |
18.00mm |
| Poles |
2 |
| Primary pack qty |
50 |
| Product name |
mPm |
| Product number display |
1212070095 |
| Product number hyphen |
121207-0095 |
| Product number sap |
1212070095 |
| Reach status |
Contains Lead per D(2024)6225-DC (07 Nov 2024) SCIP:6c8dc508-77bf-42db-b9e6-2f486123de27 |
| Reference series |
121207 |
| Ro h s status |
Compliant with Exemption 6(c) per EU 2015/863 |
| Sampleable |
False |
| Taxonomy |
Circular Industrial Connectors |
| Temperature range operating |
-40°C to +90°C |
| Upc |
884982502819 |
| Voltage maximum |
12V |
| Voltage Rating |
12V |
