Molex 1200310006 Nano-change Sensor Plug 4 Pins M8 0.30m Male

Image Representative of Range

Molex 1200310006 Nano-change Sensor Plug 4 Pins M8 0.30m Male

Molex
Order Code:

05-2844

Brand: Molex MPN: 1200310006 EAN-13: 2050007092414
Qty Was Unit Price (Ex VAT)
1+ £8.69 £7.52
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

The Molex 1200310006 is a pre-fabricated sensor/actuator connector plug featuring four RJ pins. It is designed for reliable connectivity in automation and control systems. Typical applications include industrial machinery and equipment requiring robust sensor or actuator connections.
Length 0.30m
Type Sensor/actuator connector (pre-fab)
Base unit of measure PC
Base unit of measure desc piece
China ro h s status 50 Image per SJ/T 11365-2006
Connector Type Plug
Coupling type External Thread
Current maximum per contact 3.0A
Delivery unit 20
Design registration eligibility true
ELV status Not Relevant
Engineering number 4R4F06E02C3003
Engineering Part No 4R4F06E02C3003
Engineering Series Name NC Receptacles
Engineering Series No 120031
First published date 2010-02-25
G a d s l/ i m d s Not Relevant
Gender Male
H f l h status Not Low-Halogen per IEC 61249-2-21
Industrial packaging Yes
IP Rating IP67
Key way A-Coded
Material component Nickel-plated Brass
Material type Finished Goods
Max. temperature +90°C
Min. temperature -25°C
Minimum line quantity 20
Misc Attribute Molex WOD Industrial Solution
Mounting thread size M8 x 0.5
Nema rating NEMA 6
Net weight 97.860/g
Nominal Current 3A
Nominal current - rounded value 3A
Number of Cores 4
Orientation Straight
Panel mount Front
Poles 4
Primary pack qty 10
Product name Nano-Change (M8)
Product number display 1200310006
Product number hyphen 120031-0006
Product number sap 1200310006
Prop risk status Cancer, Developmental toxicity, Reproductive toxicity
Prop sub status Lead compounds
Reach status Contains Lead; Triphenyl-phosphate; Lead monoxide per D(2025)4165-DC (25 June 2025)
Reference series 120031
Ro h s status Compliant with Exemption 6(c) per EU 2015/863
Sampleable False
Sensor/actuator connectivity fittings Front panel fitting
Taxonomy Circular Industrial Connectors
Temperature range operating -25° to +90°C
Thread type (wiring and installation) M8
Ul E152210
Upc 883906177782
Voltage maximum 60V AC / 75V DC
Wire cable type UL 1569
Wire size awg 24
