Metz Connect 11051105 RM21 Relay Module 230V AC For Large Loads

The Metz Connect RM21 230 V AC relay features a change-over contact designed for monitoring applications. Its robust construction ensures reliable operation in controlling circuits with a maximum voltage of 230 V AC. This monitoring relay is ideal for automation systems and equipment protection.

Type	Relay
Mounting Type	Plug-in
Height	75mm
Width	15.50mm
Length	75mm
AWG (min.)	12
AWG max.	22
Connection	Screw terminal
Contact Material	AgNi 90/10
Contact Type	1 change-over
Cross section (inflexible) (max.)	2.5mm²
Cross section (inflexible) (min.)	0.2mm²
Depth	65mm
Dim	(W x H x D) 15.50 x 75 x 65 mm
Factory colour	Black
Max. operating voltage	230V AC
Maximum Temperature	+55°C
Min. temperature	-20°C
Misc Attribute	RM21 230 V AC
Switching Voltage	250V AC
Switch-on current	30A
Weight	95g
