Mean Well XLG-150-M-AB XLG LED driver 150W dimmable outdoor surge-protected

Mean Well
Order Code:

05-1926

Brand: Mean Well MPN: XLG-150-M-AB EAN-13: 4021087051606
Qty Unit Price (Ex VAT)
1+ £34.14
10+ £30.73
25+ £29.50
50+ £29.21
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well XLG-150-M-AB LED driver features a constant power output of 150 W with a current range of 700 to 2100 mA and a voltage range of 60 to 107 V DC, making it suitable for outdoor use and approved for mounting on furniture. It includes an integrated PFC circuit, 3-in-1 dimming capability, and surge and overvoltage protection, fitting applications on flammable surfaces. Typical uses include powering LED strips and installations
Type LED driver
Connection Open end cable
Dim (L x W x H) 180 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 180mm
Max. output current 2100mA
Max. power 150W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant power
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 2.1A
Output current (min.) 700mA
Output voltage (max.) 107V DC
Output voltage (min.) 60V DC
Power range 150 W (max)
Test mark CE, CB, MM, ENEC, UL
Width 63mm
