Mean Well TDR-240-48 TDR Rail PSU 240W 48V DC 5A DIN-mounted fanless design

Mean Well
Order Code:

05-1876

Brand: Mean Well MPN: TDR-240-48 EAN-13: 4021087047982
Qty Unit Price (Ex VAT)
1+ £99.72
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 16/12/2025

The Mean Well TDR-240-48 is a rail-mounted power supply unit designed for industrial applications. It delivers 55 V DC at 5 A with a total power output of 240 W and features a single output via screw terminals. Ideal for use in industrial environments, this DIN rail PSU ensures reliable power delivery for control and automation systems.
Type Rail mounted PSU (DIN)
Output Voltage 48V DC
Connection Screw terminal
Dim (L x W x H) 113.5 x 63 x 125.2 mm
Efficiency 92%
Height 125.2mm
Input voltage (max.) 550V AC
Length 113.5mm
Max. output current 5A
Misc Attribute 2 Pulsed
MTBF 5154000h
Nominal Input Voltage 400 - 500 V/AC
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 5A
Output type (power supply units) Adjustable
Output voltage (max.) 55V DC
Output voltage (min.) 48V DC
Output voltage (nominal) 55V DC
Phases 3
Power 240W
PSU features Adjustable voltage output
Width 63mm
