Mean Well RPS-400-24-SF SMPSU 400.8W medical power supply low leakage

Mean Well
Order Code:

05-1466

Brand: Mean Well MPN: RPS-400-24-SF EAN-13: 4021087033985
Qty Unit Price (Ex VAT)
1+ £102.15
5+ £99.09
10+ £96.02
25+ £92.96
50+ £89.89
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 15/12/2025

The Mean Well RPS-400-24-SF is a printed circuit board power supply unit with a voltage rating of 24V and current rating of 16.7A, delivering a total power output of 400.8W. This SMPSU is designed for easy PCB mounting with solder lugs and is ideal for applications requiring reliable power conversion. Suitable for industrial and commercial use, it can efficiently power various devices and systems.
Connection Pin strip for nylon crimp connectors
Dim (L x W x H) 151 x 86.6 x 43 mm
Height 43mm
Length 151mm
Max. output current 16.7A
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 194100h
Number of Outputs 1
Output current (max.) - rounded 16.7A
Output voltage (max.) 1V
Output voltage (min.) 24V DC
PFC Yes
Type SMPSU
Width 86.6mm
