Mean Well PWM-90-12 LED transformer 90W 12V DC dimmable IP67 PFC surge protected

Mean Well
Order Code:

05-1411

Brand: Mean Well MPN: PWM-90-12 EAN-13: 4021087015196
Qty Unit Price (Ex VAT)
1+ £47.11
5+ £44.95
10+ £43.49
25+ £42.03
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well PWM-90-12 LED transformer provides a constant voltage of 12 V DC and a current range of 0 to 7.5 A, with a maximum power output of 90 W, and it is dimmable. This transformer features a PFC circuit and surge protection, making it suitable for LED strips or LED stripes applications. It is especially useful in installations where dimmable lighting is required with open end cable connections.
Type LED transformer
Connection Open end cable
Dim (L x W x H) 171.00 x 63.00 x 37.50 mm
Height 37.50mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 171.00mm
Max. output current 7.5A
Max. power 90W
Min. input voltage 90V AC
Misc Attribute 1 Constant voltage
Misc Attribute 2 Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 7.5A
Output current (min.) 0A
Output voltage (max.) 12V DC
Power range 90 W (max)
Protection Class IP20
Test mark EN61000-3-2 Class C
Width 63.00mm
