Mean Well PWM-120-12 LED driver 120W 10A 12V DC dimmable IP67 PFC Surge Protect

Mean Well
Standard range
Order Code:

05-1379

Brand: Mean Well MPN: PWM-120-12
Qty Unit Price (Ex VAT)
1+ £54.29
5+ £52.83
10+ £51.54
25+ £50.22
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
21 in stock, despatched in 4 working days

The Mean Well PWM-120-12 is an LED driver designed for constant voltage and current, delivering up to 120 W with 10 A at 12 V DC. It features a PFC circuit and surge protection, making it suitable for LED strip lighting applications. This dimmable power supply ensures efficient and reliable performance for indoor and outdoor LED installations.
Type LED driver
Connection Open end cable
Dim (L x W x H) 280 x 100 x 50 mm
Height 50mm
Input voltage (max.) 305V AC
IP rating IP67
Length 280mm
Max. output current 10A
Max. power 120W
Min. input voltage 90V AC
Misc Attribute Synchronised
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 10A
Output voltage (max.) 12V DC
Power range 120 W (max)
Protection class IP20
Test mark EN61000-3-2 Class C
Weight 970g
Width 100mm
