Mean Well MFM-15-12 MFM series SMPSU 12V 1.25A 15W medical-grade power supply

The Mean Well MFM-15-12 is a printed circuit board power supply unit capable of delivering 12 V DC at 1.25 A with a total power output of 15 W. This SMPSU is designed for PCB mounting and features solder pins for secure connections. It is typically used in applications requiring compact and efficient voltage regulation, such as industrial equipment and electronic devices.

Type	SMPSU
Nominal value output current 1	1.25A
Number of Outputs	1
Power Rating	15W
1st secondary output voltage	12V
2nd secondary output voltage	12V
3rd secondary output voltage	12V
Depth	49mm
Dimensions (L x W x H)	49 x 23.8 x 23mm
Height	23mm
Max. output current 1	1.25A
Maximum input voltage [AC]	264V
Maximum Temperature	+85°C
Min. temperature	-35°C
Minimum Input Voltage [AC]	80V
Misc Attribute 2	Pulsed
Misc Attribute 3	open
MTBF	121000h
Nominal value output voltage 1 [DC]	12V
Nominal value output voltage 2	12V
Nominal value output voltage 3	12V
Number of Inputs	1
Output voltage stabilized	12V
PFC	No
Rated supply voltage AC 50 Hz	12V
Rated supply voltage AC 60 Hz	12V
Rated supply voltage DC	12V
Type of electric connection	Solder pins
Voltage type (supply voltage)	12V
Weight	28g
Width	23.8mm
