Mean Well LPF-60D-12 LPF Series LED driver 60W 5A 7.2-12V DC Dimmable IP67

Image Representative of Range

Mean Well LPF-60D-12 LPF Series LED driver 60W 5A 7.2-12V DC Dimmable IP67

Mean Well
Standard range
Order Code:

05-1038

Brand: Mean Well MPN: LPF-60D-12
Qty Unit Price (Ex VAT)
1+ £36.76
5+ £35.80
10+ £34.89
25+ £34.01
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well LPF-60D-12 is an LED transformer that supplies constant voltage and current, rated at 60 W and 5 A with an output of 7.2 - 12 V DC. It features a power factor correction circuit and surge protection. This dimmable LED driver is ideal for powering LED strips and other constant voltage LED lighting applications.
Type LED driver
Connection Open end cable
Dim (L x W x H) 162.50 x 43.50 x 32.00 mm
Height 32.00mm
Input voltage (max.) 277V AC
IP rating IP67
Length 162.50mm
Max. output current 5A
Max. power 60W
Min. input voltage 90V AC
Misc Attribute Synchronised
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 5A
Output voltage (max.) 12V DC
Output voltage (min.) 7.2V DC
Power range 60 W (max)
Protection class II
Weight 450.00g
Width 43.50mm
