Mean Well LPF-40D-12 LED driver 40W 12V dimmable IP67 surge protection

Mean Well
Order Code:

05-1031

Brand: Mean Well MPN: LPF-40D-12 EAN-13: 4021087007542
Qty Unit Price (Ex VAT)
1+ £31.93
5+ £31.14
10+ £30.33
25+ £28.82
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well LPF-40D-12 LED driver is a constant current and constant voltage LED transformer with a 40 W power rating and a 3.34 A current rating at 7.2 - 12 V DC. It features dimmable capabilities, a PFC circuit, and surge protection, making it suitable for various LED applications. Typical uses include supporting LED strips and other lighting installations requiring reliable and adaptable power control.
Type LED driver
Connection Open end cable
Dim (L x W x H) 162.50 x 43.50 x 32.00 mm
Height 32.00mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 162.50mm
Max. output current 3.34A
Max. power 40W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 3.34A
Output voltage (max.) 12V DC
Output voltage (min.) 7.2V DC
Power range 40 W (max)
Protection Class II
Width 43.50mm
