Mean Well LPF-25D-12 LED driver 25.2W 2.1A 12V DC dimmable IP67

Mean Well
Order Code:

05-1026

Brand: Mean Well MPN: LPF-25D-12 EAN-13: 4021087007726
Qty Unit Price (Ex VAT)
1+ £25.22
5+ £23.96
10+ £23.10
25+ £22.47
50+ £21.31
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
15 in stock, despatched in 4 working days

The Mean Well LPF-25D-12 LED driver is a constant voltage and constant current transformer providing 25.2 W at 2.1 A with a 6.6 - 12 V DC dimmable output. It includes a PFC circuit and surge protection, ensuring reliable performance. This LED driver is ideal for powering LED strips and other LED lighting applications.
Type LED driver
Connection Open end cable
Dim (L x W x H) 148.00 x 40.00 x 32.00 mm
Height 32.00mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 148.00mm
Max. output current 2.1A
Max. power 25.2W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 2.1A
Output voltage (max.) 12V DC
Output voltage (min.) 6.6V DC
Power range 25.2 W (max)
Protection Class II
Width 40.00mm
