Mean Well LDD-300LS LED driver constant current 300mA 2-28V dimmable

Image Representative of Range

Mean Well LDD-300LS LED driver constant current 300mA 2-28V dimmable

Mean Well
Standard range
Order Code:

05-0993

Brand: Mean Well MPN: LDD-300LS
Qty Unit Price (Ex VAT)
1+ £5.91
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
13 in stock, despatched in 4 working days

The Mean Well LDD-300LS is a dimmable LED driver designed for constant current applications with a rating of 300 mA and a voltage range of 2 to 28 V DC. This driver is ideal for powering and controlling LED strips, providing efficient and reliable performance in lighting systems. It is commonly used in various indoor and outdoor lighting installations where precise illumination control is required.
Type LED driver
Dim (L x W x H) 25.4 x 10.5 x 9.3 mm
Factory colour Black
Height 9.3mm
Input voltage (max.) 32V DC
IP rating IP67
LED driver features dimmable
Length 25.4mm
Max. output current 300mA
Max. temperature +85°C
Min. input voltage 9V DC
Min. temperature -40°C
Misc Attribute Constant current
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 300mA
Output voltage (max.) 28V DC
Output voltage (min.) 2V DC
Test mark EAC, CE
Weight 3.4g
Width 10.5mm
