Mean Well HLG-320H-12AB LED driver dimmable 264W outdoor adjustable

Mean Well
Standard range
Order Code:

05-0824

Brand: Mean Well MPN: HLG-320H-12AB
Qty Unit Price (Ex VAT)
1+ £99.99
5+ £97.39
10+ £94.90
25+ £92.51
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well HLG-320H-12AB is a dimmable LED driver with a constant voltage output of 264 W, supporting a voltage range of 10.8 - 13.5 V DC and a current range of 11 - 22 A. This driver is designed for outdoor use, featuring a 3-in-1 dimmer, adjustable settings, PFC circuit, surge protection, and overvoltage protection. Suitable for use on furniture and flammable surfaces,
Type LED driver
Connection Open end cable
Dim (L x W x H) 252 x 90 x 43.8 mm
Factory colour Metal
Height 43.8mm
IP rating IP65
Length 252mm
Max. output current 22A
Max. power 264W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 22A
Output current (min.) 11A
Output voltage (max.) 13.5V DC
Output voltage (min.) 10.8V DC
Power range 264 W (max)
Protection class I
Test mark MM, SELV, UL, TÜV, CB, CE
Weight 1880g
Width 90mm
