Mean Well HLG-185H-24AB LED driver 187.2W dimmable PFC outdoor use

Mean Well
Order Code:

05-0797

Brand: Mean Well MPN: HLG-185H-24AB EAN-13: 4021087049504
Qty Unit Price (Ex VAT)
1+ £59.56
5+ £55.15
10+ £54.51
25+ £53.78
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
8 available to back orderBack-order availability date - 11/01/2026

The Mean Well HLG-185H-24AB is a dimmable LED driver with a constant voltage output of 22 - 27 V DC and a current rating of 3.9 - 7.8 A. It features a 3-in-1 dimmer, PFC circuit, and surge protection, making it suitable for outdoor use and use on flammable surfaces. Typical applications include powering LED strips and LED lighting in furniture and other installations requiring surge protection and adjustable dimming
Type LED driver
Output Voltage 22V DC
Max Output Power 187.2W
Output Current 3.9A
Colour Metal
Connection Open end cable
Dimensions (L x W x H) 228 x 68 x 38.8 mm
Height 38.8mm
IP Rating IP65
Length 228mm
Max. output current 7.8A
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Protection Class I
Test mark MM, SELV, UL, TÜV, CB, CE
Width 68mm
