Mean Well EPS-65-24 SMPSU 24V 2.71A 65W Open frame Universal input

The Mean Well EPS-65-24 is an open-frame switching power supply unit with a voltage output of 24 V DC and a current capacity of 2.71 A, providing a total power of 65 W. It is a compact and efficient solution suitable for PCB mounting and features solder lugs for secure connectivity. This power supply is typically used in various industrial and electronic applications where reliable and stable power is essential.

Type	SMPSU
Nominal value output current 1	2.71A
Number of Outputs	1
Power Rating	65W
1st secondary output voltage	24V
2nd secondary output voltage	24V
3rd secondary output voltage	24V
Depth	101.6mm
Dimensions (L x W x H)	101.6 x 50.8 x 29mm
Height	29mm
Max. output current 1	2.71A
Maximum input voltage [AC]	264V
Minimum Input Voltage [AC]	90V
Misc Attribute 1	Synchronised
Misc Attribute 3	open
Nominal value output voltage 1 [DC]	24V
Nominal value output voltage 2	24V
Nominal value output voltage 3	24V
Number of Inputs	1
Output voltage stabilized	24V
Rated supply voltage AC 50 Hz	24V
Rated supply voltage AC 60 Hz	24V
Rated supply voltage DC	24V
Type of electric connection	Pin strip for nylon crimp connectors
Voltage type (supply voltage)	24V
Weight	150g
Width	50.8mm
