Mean Well ELG-240-48DA-3Y LED driver 240W 24-48V DALI IP67 outdoor use

The Mean Well ELG-240-48DA-3Y is a 240W LED transformer with both constant voltage and current operation, designed for outdoor use. It offers 24 - 48 V DC output and a maximum current of 5 A, featuring surge protection and overvoltage capabilities, making it suitable for installation on flammable surfaces. With a PFC circuit and compatibility with DALI, it is ideal for powering LED lighting systems, offering reliable performance in diverse applications.

Type	LED transformer
Connection	Open end cable
Dim	(L x W x H) 244 x 71 x 37.5 mm
Factory colour	Metal
Height	37.5mm
Input voltage (max.)	305V AC
IP Rating	IP67
Length	244mm
Max. output current	5A
Max. power	240W
Max. temperature	90°C
Min. input voltage	100V AC
Min. temperature	-40°C
Misc Attribute	Synchronised
Number of Inputs	1
Number of Outputs	1
Output current (max.) - rounded	5A
Output voltage (max.)	48V DC
Output voltage (min.)	24V DC
Power (min.)	180W
Power range	180 up to 240 W
Protection Class	I
Width	71mm
