Mean Well Elg-150-36Da-3Y LED Driver 150W 36V Dali Outdoor Flammable Surface S

Mean Well ELG-150-36DA-3Y is a high-performance LED driver designed for professional lighting applications. This model provides a constant voltage and constant current output, delivering up to 150.1 watts with a rated current of 4.14 amperes and an output voltage ranging from 18 to 36 volts DC. It incorporates a PFC circuit and surge protection to enhance reliability and efficiency in outdoor settings, and it is suitable for installation on flammable surfaces, ensuring versatility in challenging environments. The inclusion of digital addressable lighting interface (DALI) control enables seamless integration into smart lighting systems, making it ideal for street lighting, architectural lighting, and general industrial lighting projects. Its robust design also includes overvoltage protection to safeguard against power surges, further enhancing its suitability for demanding engineering applications.

Type	LED transformer
Output Voltage	18V DC
Output Current	105 up to 150.1 W
Input Voltage	305V AC
Colour	Metal
Connection	Open end cable
Dimensions	(L x W x H) 219 x 63 x 35.5 mm
Height	35.5mm
IP Rating	IP67
Length	219mm
Max. output current	4.14A
Max. power	150.1W
Maximum Temperature	90°C
Min. input voltage	100V AC
Minimum Temperature	-40°C
No. of Inputs	1
No. of outputs	1
Power (min.)	105W
Protection Class	I
Weight	950g
Width	63mm
