Mean Well DLP-04L SMPSU 18.7V DC 0.24A 3.84W compact power supply

Mean Well
Order Code:

05-0368

Brand: Mean Well MPN: DLP-04L EAN-13: 4021087050616
Qty Was Unit Price (Ex VAT)
1+ £25.48 £24.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 15/12/2025

Mean Well's DLP-04L is a printed circuit board power supply unit offering 18.7 V DC at 0.24 A, delivering a total power output of 3.84 W. This SMPSU with solder lugs is ideal for applications that require a compact and efficient power solution with screw terminal connections. The unit is typically used in electronic devices where reliable DC power is needed, such as in industrial control equipment and LED lighting systems.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 145 x 38 x 22 mm
Height 22mm
Length 145mm
Max. output current 0.24A
Misc Attribute 2 closed
MTBF 625500h
Number of Outputs 1
Operating temperature (max.) +60°C
Operating temperature (min.) -20°C
Output current (max.) - rounded 240mA
Output voltage (max.) 18.7V DC
Output voltage (min.) 15.3V DC
Power 3.84W
Width 38mm
