Mean Well DKMW06F-05 DC/DC converter 24 V to 5 V 0.6 A 6 W 2 outputs

Mean Well
Standard range
Order Code:

05-0354

Brand: Mean Well MPN: DKMW06F-05
Qty Unit Price (Ex VAT)
1+ £14.91
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Mean Well DKMW06F-05 DC/DC converter is a direct current converter with an input voltage of 24 V and an output of 5 V at 0.6 A, providing a power output of 6 W. It features two outputs, making it suitable for applications requiring dual output voltages. Typical uses include industrial automation systems, telecommunications, and embedded systems where efficient voltage conversion is needed.
Type DC/DC converter
Dim (L x W x H) 25.40 x 25.40 x 11.70 mm
Efficiency (max.) 81%
Height 11.70mm
Input voltage (max.) 36V DC
Insulation voltage 1.500V
Length 25.40mm
Max. output current 0.6A
Max. temperature +85°C
Min. input voltage 9V DC
Min. temperature -40°C
Misc Attribute DKMW06F-05
No. of outputs 2
Nominal voltage 24V
Output current (max.) - rounded 600mA
Output voltages 5V
Power 6W
Weight 12.5g
Width 25.40mm
