KYOCERA/AVX 104705318 Single turn Rotary Potentiometer 0.5 W 100 kΩ

KYOCERA/AVX 104705318 is a single-turn rotary potentiometer designed for precision resistance adjustments in electronic circuits, featuring a resistance value of 100 kO and power rating of 0.5 watts. As a slide potentiometer, it allows for smooth, linear resistance changes through a rotational control element, making it suitable for applications requiring precise adjustment such as audio equipment, sensor calibration, and other analogue signal processing tasks. This component's robust construction and reliable performance make it well-suited for use in high-sensitivity environments where stable resistance is critical. Ideal for both prototyping and production, the 104705318 provides engineers with a high-quality solution for varied potentiometric control needs.

Type	10,000 cycles
Resistance	100kΩ
Power Rating	0.5W
Actuating Force	3.6Ncm
Axle Diameter	6mm
Axle length	50mm
Case Dimensions	24mm
Connection	Solder tag
Content	1
Cut-off Voltage	500V
Diameter	24mm
Dimensions	(Ø x L) 24 mm x 11.5 mm
Electrical Angle	270°
Impact Tolerance	113Ncm
Insulation Resistance	1500V
Length	11.5mm
Maximum Temperature	+70°C
Mechanical Angle	320°
Minimum Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Temperature Coefficient	500ppm/°C
Thread Length	8mm
Thread Size	M10
Tolerance ±	0.2%
