KYOCERA/AVX 104705315 Single turn Rotary Potentiometer 0.5 W 100 kΩ

KYOCERA/AVX 104705315 is a single turn rotary potentiometer designed for precision control applications. This slide potentiometer is rated at 0.5 watts and offers a resistance value of 100 kilohms, providing reliable and consistent performance within its operational parameters. The device's construction ensures durability and smooth operation, making it suitable for tasks that require precise adjustments in resistance, such as in audio equipment, measurement instruments, and other electronic circuits where fine tuning of electrical signals is necessary. Its compact design allows for integration into a variety of electronic assemblies, providing engineers with a versatile component for both prototyping and production designs.

Type	104705315
Resistance	100kO
No of Turns	1
Power Rating	0.5W
Actuating Force	3.6Ncm
Axle Diameter	6mm
Case Dimensions	24mm
Connection	Solder tag
Content	1
Cut-off Voltage	500V
Diameter	24mm
Dimensions	(Ø x L) 24 mm x 11.5 mm
Electrical Angle	270°
Impact Tolerance	113Ncm
Length	11.5mm
Lever Length	50mm
Max. temperature	+70°C
Maximum Temperature	+70°C
Mechanical Angle	320°
Min. temperature	-25°C
Minimum Operating Temperature	-25°C
Output	Mono
Product Type	Single turn rotary pot
Resistance characteristic	linear
Temperature Coefficient	500ppm/°C
Thread Length	8mm
Thread Size	M10
Tolerance ±	0.2%
