Knorr Tec 10015620 D-SUB Plug 180° 9 Pins Pull Spring Vibration Secure

The Knorr Tec D-SUB plug 10015620 is a 9-pin connector with a 180-degree design and pull spring. It is ideal for telecom and IT applications, providing reliable connections in electronic systems. This connector, with its robust construction, is well-suited for secure installation in various communication devices.

Type	D-SUB plug
Plug / Socket	Plug, straight
Mounting Type	BackShell Mounting
No. of Ways	9
Mounting Direction	180 Degree
Connection Angle	180°
Casing	Plastic housing, ABS metallic (EMV-Variante)
Height	16.6mm
IP Rating	IP20
Length	60mm
Misc Attribute 1	Connector
No. of Rows	2
Nominal voltage (details)	≤ 100V
Number of pins	9
Pins	9
Temperature Range	-20 to +85°C
Test Voltage	1 KV/mm
Width	31mm
