KNIPEX 77 52 115 Electronics Diagonal Cutter with Box Joint 115 mm

77 52 115 Electronics Diagonal Cutter
Durable, load-optimised design with backlash-free box joint. High, slim sleeves for fine and comfortable gripping between thumb and index finger. Less physical effort due to very high transmission ratio. Load-optimised for a more direct feel when working. Low-friction double spring for smooth and even opening. The mirror polish in combination with a fine oil film provides rust protection - no circuit faults caused by peeling chrome from plated tools. Cutters additionally laser hardened, cutter hardness at least 62 HRC. pointed, flat head, with small bevel.

Cutting capacities medium hard wire (diameter): Ø 0.8 mm

Cutting capacities hard wire (diameter): Ø 0.5 mm

Cutting capacities soft wire (diameter): Ø 0.3 – 1 mm

Jaw length (B): 14 mm

Jaw thickness (joint) (D): 7.5 mm

Head width (A): 11 mm

Type	Side cutter
ESD Safe	No
Length	115mm
VDE Safe	No
Bevel	cutting edges with small bevel
Cutting capacities soft wire (diameter)	0.3 - 1mm
DIN Standard	DIN ISO 9654
Edge hardness	60HRC
Handles	with multi-component grips
Head	mirror polished
Head width	11mm
Height	48mm
Jaw Length	14mm
Jaw Thickness	7.5mm
Joint Design	box joint
Material	Tool steel
Rack size	483 mm (19")
Range of use	Electrician
Weight	75g
Width	71mm
Wire hardness (max.) hard wire	0.5mm
Wire hardness (max.) medium wire	0.8mm
Wire hardness (max.) soft wire	1mm
