JST ZHR-7 Socket Housing 7 Pins 1.50mm Spacing Cable-Board Secure

Image Representative of Range

JST ZHR-7 Socket Housing 7 Pins 1.50mm Spacing Cable-Board Secure

JST
Order Code:

04-4978

Brand: JST MPN: ZHR-7 EAN-13: 2050000918049
Qty Unit Price (Ex VAT)
50+ £0.130
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
351 in stock, despatched in 4 working days

The JST ZHR-7 is a 7-pin socket housing with a contact spacing of 1.50 mm. It measures 12x3.4x4.2 mm and is ideal for use in printed circuit board connectors. This component is suited for various electronic and electrical applications requiring reliable cable connections.
Type Socket housing cable
Number of Ways 7
Number of Rows 1
Colour Ecru
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.032 - 0.13mm²
CS 1.50mm
Dimensions (L x W x H) 12 x 3.4 x 4.3 mm
Height 4.3mm
Industrial packaging No
Insulation Material Polyamide
Length 12mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pins per row 7
Series ZHR
Width 3.4mm
