JST ZHR-5 Socket Housing 5 Pins 1.50mm Spacing Reverse Voltage Protection

Image Representative of Range

JST ZHR-5 Socket Housing 5 Pins 1.50mm Spacing Reverse Voltage Protection

JST
Order Code:

04-4976

Brand: JST MPN: ZHR-5 EAN-13: 2050000918025
Qty Unit Price (Ex VAT)
100+ £0.078
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
1,405 in stock, despatched in 4 working days

JST socket housing cable ZHR-5 is a component with a total of 5 pins and a contact spacing of 1.50 mm. It is typically used in PCB connectors and measures 9x3.4x4.2 mm. This product is renowned for its compact size and reliability in electronic connections.
Type Socket housing cable
Number of Ways 5
Number of Rows 1
Colour Ecru
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.032 - 0.13mm²
CS 1.50mm
Dimensions (L x W x H) 9 x 3.4 x 4.3 mm
Height 4.3mm
Industrial packaging No
Insulation Material Polyamide
Length 9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pins per row 5
Series ZHR
Width 3.4mm
