JST ZHR-12 Socket Housing Cable 12 Pins 1.50mm PCB Connection

Image Representative of Range

JST ZHR-12 Socket Housing Cable 12 Pins 1.50mm PCB Connection

JST
Order Code:

04-4972

Brand: JST MPN: ZHR-12 EAN-13: 2050000918087
Qty Unit Price (Ex VAT)
25+ £0.186
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
95 available to back orderBack-order availability date - 10/01/2026

The JST socket housing cable ZHR-12 is a component featuring 12 pins with a contact spacing of 1.50 mm, measuring 19.5x3.4x4.2 mm. It is typically used in various electronic assemblies for connecting PCBs. Manufactured by J.S.T., this product is ideal for applications requiring reliable and compact connector solutions.
Type Socket housing cable
Number of Ways 12
Number of Rows 1
Colour Ecru
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.032 - 0.13mm²
CS 1.50mm
Dimensions (L x W x H) 19.5 x 3.4 x 4.3 mm
Height 4.3mm
Industrial packaging No
Insulation Material Polyamide
Length 19.5mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pins per row 12
Series ZHR
Width 3.4mm
