JST ZHR-10 Socket Housing Cable 10 Pins 1.50mm Reverse Voltage Protection

Image Representative of Range

JST ZHR-10 Socket Housing Cable 10 Pins 1.50mm Reverse Voltage Protection

JST
Order Code:

04-4971

Brand: JST MPN: ZHR-10 EAN-13: 2050000918070
Qty Unit Price (Ex VAT)
50+ £0.125
250+ £0.124
1000+ £0.112
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
289 in stock, despatched in 4 working days

The JST socket housing cable ZHR-10 is a compact connector featuring 10 pins with a 1.50 mm contact spacing. Manufactured by J.S.T., it measures 16.5x3.4x4.2mm and is used in PCB connectors and components. Typical applications include electronics and circuit board connections.
Type Socket housing cable
Number of Ways 10
Number of Rows 1
Colour Ecru
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.032 - 0.13mm²
CS 1.50mm
Dimensions (L x W x H) 16.5 x 3.4 x 4.3 mm
Height 4.3mm
Industrial packaging No
Insulation Material Polyamide
Length 16.5mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pins per row 10
Series ZHR
Width 3.4mm
