JST VHR-6N VH Socket 6 Pins 3.96mm Vibration Proof Reverse Protection

Image Representative of Range

JST VHR-6N VH Socket 6 Pins 3.96mm Vibration Proof Reverse Protection

JST
Order Code:

04-4961

Brand: JST MPN: VHR-6N EAN-13: 2050000917820
Qty Unit Price (Ex VAT)
50+ £0.154
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 4 weeks

The JST VHR-6N is a socket housing designed for secure and reliable connections, featuring six pins with a contact spacing of 3.96 mm. Manufactured by JST, this component is compact with dimensions of 23.7 x 10.5 x 13.3 mm and is commonly used in PCB connector applications. It is ideal for assembling electronic components where space and efficiency are crucial.
Type SIL socket (standard)
Board contact surface Tin plated
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.33 - 1.25mm²
CS 3.96mm
Dim (L x W x H) 23.7 x 14.6 x 8.5 mm
Factory colour Ecru
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 23.7mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal Voltage 250V AC
Nominal voltage (details) 250V AC
Number of Rows 1
Pins 6
Pins per row 6
Series VH
Total number of pins 6
Width 14.6mm
