JST VHR-5N Socket VH 5-Pin 3.96mm Spacing Reverse Voltage Protection

Image Representative of Range

JST VHR-5N Socket VH 5-Pin 3.96mm Spacing Reverse Voltage Protection

JST
Order Code:

04-4960

Brand: JST MPN: VHR-5N EAN-13: 2050000917813
Qty Unit Price (Ex VAT)
25+ £0.200
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
27 in stock, despatched in 4 working days

The JST VHR-5N is a socket housing with 5 pins and a contact spacing of 3.96 mm. Measuring 19.74 x 10.5 x 13.3 mm, it is used in connectors and PCB applications. This component is ideal for standard SIL socket connections in electronic devices.
Type SIL socket (standard)
Board contact surface Tin plated
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.33 - 1.25mm²
CS 3.96mm
Dim (L x W x H) 19.74 x 14.6 x 8.5 mm
Factory colour Ecru
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 19.74mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal Voltage 250V AC
Nominal voltage (details) 250V AC
Number of Rows 1
Pins 5
Pins per row 5
Series VH
Total number of pins 5
Width 14.6mm
